摩擦系数是针对塑料薄膜和薄片在自身或其他材料表面滑动时静摩擦系数和动摩擦系数的测定而研制的，能够满足GB/T1006-1988《塑料——薄膜和薄片——摩擦系数的测定》，是各级质检部门和生产企业的理想测试设备，可为您提供准确的试验结果。

产品名称：摩擦系数仪，摩擦系数测定仪，摩擦系数检测仪，摩擦系数试验机，摩擦系数测试仪，摩擦系数测量仪

产品型号：MXZ-01

价格：优惠促销，欢迎来电咨询！

产品概述:     适用于测量塑料薄膜和薄片、橡胶、纸张、纸板、编织袋、织物风格、输送带、木材、涂层等材料滑动时的动、静摩擦系数。通过测量材料的滑爽性，可以控制调节材料生产质量工艺指标，满足产品使用要求。

产品特点:

1.嵌入式智能控制，试验过程自动化

2.采用高精度力量传感器，达到国内最高测试精度：0.001N

3.无机械旋钮，全数字化系统，数字校正与调零

4.特殊设计的驱动系统，运行平稳，测试结果更准确

5.液晶屏实时显示力值及动、静摩擦系数

6.测试报告设计精美

7.成组数据，内嵌数据统计分析功能

8.操作简单，使用方便

技术参数:

1.测力范围   0～5 N

2.测量精度   1级

3.滑块行程   150 mm

4.滑块质量   200g

5.试验速度   100mm/min

6.试验条件   标准试验环境

7.主机尺寸   520 mm×330 mm×230mm（L×B×H）

8.电    源   AC 220V±10％50Hz

9.净    重   35Kg

依据标准:GB 10006、GB/T 17200、ISO 8295、ASTM D1894、TAPPI T816

标准配置:主机、微型打印机、200g滑块、通讯电缆

Installation

MXZ-1 friction coefficient tester, as a precision measuring device, requires careful installation, adjustment and clean working environment, to guarantee testing accuracy and normal operation.

5.1 before unpacking, please check first to see if the package is in good condition. Then open the case, refer to the packing list, check if the device and accessories are complete, and then take out the device carefully;

5.2 put the device in a stable platform, adjust the adjusting nut below the main frame, make the level bubble in the middle;

5.3 plug the power line in a three-pin socket, turn on power switch, then it is ready for testing.

4. Usage and operation

Thin film(slice ) to thin film (slice)

6.1 make one specimen’s surface upward, then fix it flat on the level test bench; make sure the sample is parallel to the length direction of the test bench;

6.2 make the other specimen’s surface downward to wrap the slider, fix the specimen to the front side and upper surface of the slider with adhesive tape;

6.3 put the slider with fixed specimen(6.2) on the center part of the first specimen(6.1); make sure the testing direction is parallel to the slider and the force measuring system is not affected by force;

6.4 the first peak value of the force is static friction force (Fs); the average force (not including the static friction force) caused by relative motion of the two specimens within 60mm is dynamic friction force(Fd);

6.5 if the force value is unstable after static friction force appears, the dynamic friction force might not be correct. In this case, take out the spring between the slider and the load sensor, and measure the dynamic friction force separately.

Thin film (slice) to other materials

When testing the friction force between plastic film (slice) and other material surface, users should fix the plastic film(slice) on the slider and fix the other material specimen on the level test bench. And then repeat the procedures as above (from 6.1 to 6.5)
